Оригинальный видоискатель AU-VCVF20G Panasonic.
he Electronic HD Color View Finder for VariCam LT supports 1080p, 1080PsF, and 1080i video resolutions via SDI. It features an adjustable diopter range of -3.6 to +1.4, which makes it well suited for many different camera operators. You can access focus peaking as well as waveform (in single color and parade). The View Finder also allows you to zoom in on the image to check focus. Two user-assignable function buttons allow you to quickly access oft-used functions. The display also features both a red and green tally indicator, active when the camera is recording/in standby or when a tally signal is received.
Panasonic AU-VCVF20GJ Specs
Display
Color/Monochrome |
Color |
Panel Type |
OLED |
Display Size |
0.7" / 1.8 cm |
Screen Resolution |
1920 x 1080 |
Touchscreen |
No |
Image Controls |
Focus Peaking, RGB Parade, Waveform |
I/O
Video |
1 x BNC (3G-SDI) Input |
Video Format |
SDI
1080p: 60/59.94/50
1080PsF: 29.97/25/24/23.98
1080i: 59.94/50 |
Camera Connection |
4-Pin Panasonic |
Optics
Diopter Correction |
-3.6 to +1.4 |
Environmental
Operating Humidity |
10 to 85% |
Operating Temperature |
32 to 104°F / 0 to 40°C |
Storage Temperature |
-4 to 140°F / -20 to 60°C |
General
Mounting |
1 x Accessory Rail |
Dimensions (W x H x D) |
3.7 x 3.46 x 4.37" / 94 x 88 x 111 mm |
Weight |
2.2 lb / 1.00 kg |
Packaging Info
Package Weight |
3.72 lb |
Box Dimensions (LxWxH) |
14 x 10.9 x 6.95" |
