HDMI 2.0 в 12G-SDI/(Option: Quad-Link 3G-SDI) Up/DownКонвертор
Model | HDMI 2.0 to 12G-SDI |
---|---|
Description | HDMI 2.0 to 12G-SDI Converter |
Feature | Multi-Standard Support ( 12G / 6G / 3G / HD / SD-SDI ) Auto Source Format Detection |
Input Interface | Video HDMI 2.0×1 |
Output Interface | Converted Video 12G-SDI×2 HDMI 2.0×1 |
Supported Video Input Format | HDMI 2.0 4096×2160p@60/50fps 4096×2160p@30/25/24fps 3840×2160p@60/50fps 3840×2160p@30/25/24fps 1920×1080p@60/50fps 1920×1080p@30/25/24fps 1920×1080i@60/50fps 1280×720p@60/50fps 720×480p@60fps 720×576p@50fps 720×480i@60fps 720×576i@50fps |
Supported Video Output Format | HDMI : As input HDMI format SDI : As input HDMI format |
Audio Input Format | HDMI : 8 Channels, 24bit, Up to 192KHz |
Audio Output Format | SDI : 8 Channels, 24bit, 48KHz HDMI : 8 Channels, 24bit, Up to 192KHz |
Plug & Play | V |
DC In | 7.5V ~ 15V |
