Конверторы видеосигналов Kiloview CV190 Video converter конвертер

Model

CV190

Input

1*HDMI, 1*VGA, 1*BNC AV(CVBS), 1*3.5mm dual channel analog audio (1Vp-p)

Output

2*BNC-SDI (SD/HD/3G)

Input format

HDMI: 480i,576i,480p, 576p, 720p@50/59.94/60,1080i@50/59.94/60,

1080p@24/25/29.97/30, 1080p50/59.94/60, compatible with VGA format, up to 1920x1080@60Hz;

VGA: up to 1920x1080@60Hz, support all VESA standard resolution and common non-vesa resolution;

YPbPr: (using VGA-YPbPr), support 720p50/59.94/60,1080i50/59.94/60 and 1080p24/25/29.97/30/50/59.94/60;

AV(CVBS): PAL (576i)/NTSC (480i).

SDI transmitting distance

SDI transmitting distance Belden 1694A: SD-SDI 400m, HD-SDI 200m, 3G-SDI 120m.

Note: different cables have different transmission distances.

Framerate/resolution conversion

Support

Audio embedding

Support

Management

Remote control/ PC connection with USB

Power supply

12V, 1A

Consumption

4w

Operation temperature

-20~60°C

Dimension

120*100*26mm（4.72*3.94*1.02”）

Weight

315g（11.1oz）
