Yuan UB570G PRO 12G-SDI HDR

Yuan UB570G PRO 12G-SDI HDR

Артикул 13637
Производитель: Yuan
Цена: 124 630 руб.
Рейтинг:comment rank 5
Просмотров 400
Официальная гарантия

Только под заказ!
Итого:  Кол-во
Заказать



Model UB570G PRO 12G-SDI
Max. FPS 4096×2160p@60/50fps
Recording Mode Software Compression, Real-Time Mode
Interface USB3.0 Type B ( SuperSpeed ) UVC
Video Input Single Link 12G-SDI or Quad Link 3G-SDI ( Option : Dual Link 6G-SDI )
Video Output 1×12G-SDI ( Option : Loop-through, For Single Link 12G-SDI )
Video RAW Data Format YUY2, P010 ( Support on Outputs Below 1080P60 )
NV12, I420 ( Supports on All Outputs )
Video Input Resolution USB3.0 Support Resolution
All Resolution Below
4096×2160p@60fps
( Option : 444 10Bit )
Recording Video Format YUY2, P010, NV12, I420 ( USB3.0 )
UVC Video Output Resolution USB3.0 Support Resolution
4096×2160p@60 / 50fps and 3840×2160p@60 / 50fps inputs will transfer to
3840×2160p@30fps ( NV12, I420 ) or 1920×1080p@60fps ( YUY2, P010 )
For all inputs below 3840×2160p@30fps, UB570G PRO SDI-12G outputs will be the same
Audio Input SDI Embedded Audio
3.5mm Analog Stereo Audio
Audio Output SDI Embedded Audio
UAC Audio Output Format Stereo / 16-bit / 48000Hz
  System Requirement
OS Support Windows 7 / Windows 8.1 / Windows 10 ( 32-bit and 64-bit )
Linux / MAC OS / Android
