4×3G-SDI to 12G-SDI/HDMI2.0 Up/Down Converter
Model Name | QSDI to 12G-SDI/HDMI2.0-S |
Description | Quad-Link 3G-SDI to 12G-SDI/HDMI 2.0 Up/Down Converter |
Feature | Quad-Link 2 Sample Interleave ( 2SI ) Supported Square Division Quad Supported Quad-Link 3G-SDI Supported 60fps ↔ 59.94fps Conversion Multi-Standard Support ( 12G/6G/3G/HD-SDI ) Auto Source Format Detection |
Input Interface | Video 3G-SDI×4 |
Output Interface | Up/Down Converted Video HDMI 2.0×1 12G-SDI×2 Audio 3.5 mm Phone Jack×1 |
Supported Video Input Format | SDI Quad-Link 3G-SDI 4096x2160p@60/50fps 3840x2160p@60/50fps Dual-Link 3G-SDI 4096x2160p@30/25/24fps 3840x2160p@30/25/24fps 3G-SDI 1920×1080p@60/50fps HD-SDI 1920×1080p@30/25/24fps 1920×1080i@60/50fps 1280×720p@60/50fps SD-SDI 720×480i@60fps 720×576i@50fps |
Supported Video Output Format | SDI ( Up/Down Converted ) 12G-SDI 4096x2160p@60/50fps 3840x2160p@60/50fps 6G-SDI 4096x2160p@30/25/24fps 3840x2160p@30/25/24fps 3G-SDI 1920×1080p@60/50fps HD-SDI 1920×1080p@30/25/24fps 1920×1080i@60/50fps 1280×720p@60/50fps SD-SDI 720×480i@60fps 720×576i@50fps HDMI 2.0 ( Up/Down Converted ) 4096x2160p@60/50fps 4096x2160p@30/25/24fps 3840x2160p@60/50fps 3840x2160p@30/25/24fps 1920×1080p@60/50fps 1920×1080p@30/25/24fps 1920×1080i@60/50fps 1280×720p@60/50fps 1280×1024p@60fps 1280×960p@60fps 1024×768p@60fps 800×600p@60fps 640×480p@60fps 720×480p@60fps 720×576p@50fps 720×480i@60fps 720×576i@50fps |
GENLOCK Frame Lock Mode | N/A |
Audio Input Format | SDI : Up to 8 Channels, 24bit, 48KHz |
Audio Output Format | HDMI : 8 Channels, 24bit, Up to 192KHz SDI : Up to 8 Channels, 24bit, 48KHz 3.5 mm Phone Jack : 2 Channels, 24bit, 48KHz |
Plug & Play | ✓ |
DC In | 7.5V ~ 15V |
Dimension | L:180mm×W:76mm×H:36mm |
