Каталог > Монтажное оборудование > Конверторы видеосигналов > Yuan > Yuan SC6E0N1 AIO Lite
Конверторы видеосигналов Yuan SC6E0N1 AIO Lite

Конверторы видеосигналов Yuan SC6E0N1 AIO Lite

Артикул 14617
Производитель: Yuan
Цена: 100 188 руб.
Рейтинг:comment rank 5
Просмотров 130
Официальная гарантия

Только под заказ!
Итого:  Кол-во
Заказать

SC6E0N1 AIO Lite

1CH SDI+HDMI 1080P60 ENCODER+DECODER

SC6E0N1 AIO Lite

Model Name SC6E0N1 AIO Lite
Max. FPS 1920×1080p@60/50fps
Recording Mode Hardware Compression, Real-Time Mode
CPU N/A
5G Support N/A
A/V Input Interfaces Video
1×HDMI
1×SDI

Audio
1×3.5 mm Phone Jack
A/V Output Interface Video
1×HDMI2.0 (PGM)
1×HDMI (Loop-through)
1×SDI (Loop-through)

Audio
1×3.5 mm Phone Jack
Video Feature H.265/H.264/AVC, Baseline/Main/High Profile

Support input / output resolutions
3840×2160p@60/50fps (Output only)
3840×2160p@30/25/24fps (Output only)
1920×1080p@60/50fps
1920×1080p@30/25/24fps
1920×1080i@60/50fps
1280×720p@60/50fps
1280×1024p@60fps
1280×960p@60fps
1024×768p@60fps
800×600p@60fps
640×480p@60fps
720×480p@60fps
720×576p@50fps
720×480i@60fps
720×576i@50fps
Video Encode N/A
Audio Feature Input Audio Stream:
AAC
Network Feature 1×RJ45 for 10/100/1000Mbps Ethernet
DHCP Client
Support Streaming protocol NDI Support ( Separate License with NDI Required )
Dante AV-H ( Separate License with Dante AV-H Required )
TS Over UDP ( Unicast & Multicast )
RTSP Over HTTP/TCP/UDP ( RTSP Elementary Stream )
RTMP ( Publish )
HLS
Misc. Features 1×USB 3.0 Host for USB Storage
2×USB 2.0 (For Keyboard and mouse usage)
Web UI for System Configuration
Firmware Upgradable
LED Indicator
PGM mode switch N/A
Support Record Device N/A
SDK Support N/A
AI Features N/A
Record Format MP4 / TS / MOV
Power Supply DC input : 12V / 2A
