Datavideo VP-597

Datavideo VP-597

Артикул 07055
Производитель: Datavideo
Цена: 63 551 руб.
Рейтинг:comment rank 5
Просмотров 3094
Официальная гарантия

Есть в наличии!
Бесплатная доставка по Москве в пределах МКАД!
Итого:  Кол-во
Заказать

2x6 3G HD/SD-SDI Distribution Amplifier

2 x 3G/HD/SD-SDI inputs and 6 x 3G/HD/SD-SDI distribution outputs



Supports 3G/HD/SD SDI video with embedded Audio and re-clock design for long distance transmission.

Supports embedded audio SDI



VP-597 is ideal for simple A/B source switching to multiple HD displays or it can be used as a backup 3G/HD/SD SDI input sources switcher for live events.

Two input video can be controlled by A/B switch or GPI remote



Datavideo VP-597 is a six output SDI distribution amplifier with A/B inputs switching control (non-locked)

Specifications

VP-597 2x6 3G HD/SD-SDI Distribution Amplifier
Video Input/Output

Input: 2 x BNC
Output: 6 x BNC

Video Format

1080p 60/59.94/50/29.97/23.98
1080i 60/59.94/50
720p 60/59.94/50
525i, 625i

Audio Format

Support SDI embedded audio
Up to 8 channels, 48KHz, PCM audio

Power

12V / 2.8W

Dimension (LxWxH)

127 x 85 x 45 mm

Weight

0.5 kg

Operating Temp. Range

0~40 °C

What's in the Box

1 x VP-597 product
1 x AD Switch 12V 500mA
1 x 3.5Φ GPI Cable Stereo
1 x Thank You Card
