LCD
Size
21.5"
Resolution
1920 x 1080
Pixel Pitch
0.248mm
Color
16.7M(8bit)
Viewing Angle
178(H), 178(V)
Luminance of White
1200 cd/m²
Contrast
3000 : 1
Display Area (H X V)
476.64 x 268.11 (mm)
Back Light
LED
INPUT
1 x HDMI
HDMI (with HDCP v.1.1), 19pin Female
1 x DVI
DVI-I, 24pin, Female
1 x VGA
DVI-I to VGA Jack (with gender)
2 x BNC
SDI Input
3 x BNC
Analog(YPbPr/CVBS/S-Video/RGB)
OUTPUT
2 x BNC
SDI-1/2 Active Loop Output
3 x BNC
Analog(YPbPr/CVBS/S-Video/RGB)
Composite
1.0Vp-p(with sync), NTSC/PAL
YC(S-Video)
Y :1.0Vp-p, C:0.286Vp-p
Component(Y/Pb/Pr)
Y :1.0Vp-p, Pb :0.7Vp-p, Pr :0.7Vp-p
Component (R/G/B)
G :1.0Vp-p(with Sync), B :0.7Vp-p, R :0.7Vp-p
PC-RGB,Sync Level
R, G, B : 0.7Vp-p, H/V Sync : 4V ± 1Vp-p
AUDIO
1 x Phone Jack In
Line In(Stereo)
2 x Phone Jack Out
Line Out(Rear, Stereo), Headphone Out(Front, Stereo)
2 x Speaker Out
2W+2W, Stereo
FORMAT
SMPTE 425M AB
1080/60p, Level A MS1, MS2, MS3, MS4
Level B MS1, MS2, MS3, MS4
Level B MS1, MS2, MS3, MS4
2K, SMPTE 428M
2048*1080,24p/psf,23.98p/psf
SMPTE 274M/292M
1920*1080i (60, 59.94, 50)
1920*1080p (30, 29.97, 25, 24, 24sF, 23.98, 23.98sF)
1920*1080p (30, 29.97, 25, 24, 24sF, 23.98, 23.98sF)
SMPTE 296M
1280*720p/60,59.94,50
SMPTE 260M
1920*1035i/60,59.94
SMPTE 125M/259M
720*480i/60,59.94, 720*576i/50
ITU R-BT.656
576i(50)
Composite
720*480i(NTSC)/576i(PAL)
Component, VGA
480i/p ~ 1920 * 1080i/p
DVI Signal
480i/p ~ 1920 * 1080i/p
HDMI Digital
~ 1920 * 1200i/p(de-embedded Audio 2ch)
GENERAL
1 x Ethernet
Control/Update, GPI-7 Port, RJ-45P Jack
2 x GPIO
GPI-7 Port, RJ-45P Jack
2 x Serial
RS-422, RJ-11P Jack
1 x USB
for firmware update
Power Requirements
DC 12V/24V, AC100-230V(50/60Hz)
Power Consumption
90W
Operating Temperature
0°C ~ 40°C (32°F~104°F)
Operating Humidity
20% ~ 80% RH
Weight
6 kg (13.2 lbs)
Dimensions(WxHxD)
503.6 x 348.0 x 65.2mm(19.8 x 13.7 x 2.5 inches)
Accessories
• Power Cable • Manual • Cleaner
Option
• V-Mount • Anton Bauer • SunHood • Protect • Wall Bracket • Carrying Case • Rack Mount
